Manual and Pneumatic Extraction Modes
Easy Fluid Changes
Works for Engine Oil, Brake Fluid, & Coolant
Valuable Tool to Add to Your Garage

Description
Vehicle Fitment
Included

Mishimoto 5.6L Fluid Extractor - Manual and Pneumatic (MMTL-FEX-MP56)

If you've built your K-swap, B-swap, or H22 project in a driveway, an apartment garage, or anywhere without a lift, you already know the dance. Jack the car up, slide the stands under, crawl on your back with a drain pan, hope the oil doesn't run down your sleeve, fight the drain plug you torqued a little too hard last time, then find out your crush washer's the wrong size. A 20-minute fluid change turns into an hour, all because the access geometry isn't on your side. This is the shortcut. Drop the tube down your dipstick, pump the fluid up into the 5.6 liter canister, dump it in your recycle jug, done. No jack stands, no oil on the concrete, no skinned knuckles.

What It Actually Does

The Mishimoto MMTL-FEX-MP56 is a 5.6 liter (1.5 gallon) sealed canister with a vacuum pump that pulls low-viscosity fluid up through a long, flexible draw straw. You can run it two ways: manual hand pump when you're in a driveway or anywhere shop air isn't handy, or pneumatic mode that hooks to your compressor and does the work hands-off. Pneumatic's faster since the compressor's doing the pumping, but the manual mode means the tool isn't dead weight the second you're away from an air line. It handles engine oil, automatic transmission fluid, coolant, power steering fluid, and brake fluid, so it's not a one-trick oil-change tool.

The Bleeder Adapter Is The Sleeper Feature

Here's the part that makes this more than an oil sucker: the kit includes a bleeder screw adapter, and that's what turns it into a full fluid maintenance tool. Pop the bleeder screw on a brake caliper, thread the adapter on, and the extractor pulls a full brake bleed through suction, no helper pumping the pedal, no pressure bottle. Same deal for bleeding the clutch on a hydraulic-clutch car. If you've ever tried to bleed brakes solo and ended up yelling "down... up... hold!" through a cracked window, you'll appreciate what this does.

Why It Works So Well On A Honda

This is where the extractor really shines on the cars you're probably working on. K-series, B-series, D-series, and H-series engines all run straight-shot dipstick tubes that route right down to the oil pan with barely any curve. The 7mm straw slides down a typical Honda dipstick tube and reaches the bottom of the pan, so you actually pull most of the oil out. People always ask whether an extractor leaves a meaningful amount behind, and on Honda dipstick geometry, the honest answer is no, not on any of these engines. You're getting a real, complete oil change, not a half-measure.

Know Its Limits

Be straight about what this tool is for: low-viscosity fluids only. Don't try to pull gear oil out of a diff, manual transmission fluid (most of it's too thick at room temp), or anything that's been sitting cold and turned to syrup. The pump just can't move fluid that thick. And warm your engine up to operating temp before you extract oil, since warm oil flows the way the pump needs it to. For the really thick stuff, you're back under the car with a drain plug, that's just how it goes.

Specs
- Manufacturer: Mishimoto
- Part number: MMTL-FEX-MP56
- Capacity: 5.6 liters (1.5 gallons)
- Operation: manual hand pump and pneumatic (shop air)
- Recommended air pressure: 85 psi
- Maximum air pressure: 120 psi
- Compatible fluids: engine oil, ATF, coolant, power steering fluid, brake fluid
- Automatic float shutoff to prevent overfill
- Removable lid for clean disposal and recycling
- Mishimoto Lifetime Warranty
Is 5.6 Liters The Right Size For You?

For a single Honda or Acura engine oil change, 5.6 liters is plenty with room to spare. A K20A2 holds about 4.4 quarts (4.2L), a K24A about 4.6 quarts (4.4L), a B18C about 4.3 quarts (4.1L), and an H22A4 about 4.3 quarts (4.1L), so every one of them fits in the canister with margin left over. The only time you'd want the bigger 9.5L MMTL-FEX-MP95 instead is if you're knocking out back-to-back oil changes on multiple cars without dumping in between, or flushing a coolant system that holds 7+ liters, which is unusual for these chassis. For a one-car driveway or apartment-garage routine, the 5.6L is the right size, and the price reflects that.

Warm It Up First, Then Extract

This one tip makes a real difference. Cold oil is roughly twice as thick as oil at operating temp, and you'll feel that in how slow the pump pulls. So run the car for 5 to 10 minutes to bring the oil temp up, shut it off, then let it sit a minute or two so the oil drains back down to the pan before you extract. Don't go yanking it right after a long highway run either, when the oil's hot and sloshing around you'll get inconsistent levels. A few minutes of patience gets you a clean, complete pull.

Bleeding Brakes By Yourself

The bleeder adapter is what makes this genuinely useful for brake service. Most home brake bleeds need either a buddy pumping the pedal or a pressure-fed bottle, but this pulls the fluid out right at the caliper through suction, so one person does a full four-corner bleed with no coordination at all. Your sequence is still the usual right rear, left rear, right front, left front (longest lines first) on most front-engine cars, and you've still got to keep the master cylinder topped off so you don't suck air back in. Same procedure as always, the extractor just makes it faster and a whole lot cleaner.

Recycle The Old Fluid The Right Way

Quick reminder: most auto parts stores take used motor oil and coolant for free or close to it, and the removable lid on this canister makes pouring it into a recycle jug clean and direct. Don't dump it on the ground, don't toss it in your trash. The whole point of a tool that keeps your floor clean is wasted if the old fluid ends up somewhere it shouldn't.

The Lifetime Warranty Is The Real Deal

Mishimoto's lifetime warranty actually means something. On the rare occasion we've sent a customer back to Mishimoto on a warranty case across their product line, they've handled it cleanly, no runaround. For a tool you'll own for the next decade-plus of fluid changes, that's the kind of warranty that matters. Buy it once, use it on every oil change you do for the next ten years, and you've spent less per change than the dealer charges for a single one.

What You Get
- Mishimoto 5.6L (1.5 gallon) fluid extractor (MMTL-FEX-MP56)
- Manual hand pump and pneumatic (shop air) operation
- Long flexible draw straw (7mm) for Honda/Acura dipstick tubes
- Bleeder screw adapter for solo brake and clutch bleeding
- Automatic float shutoff and removable lid for clean disposal
- Works with engine oil, ATF, coolant, power steering fluid, and brake fluid
- Backed by Mishimoto's Lifetime Warranty
Note: Mishimoto fluid extractor, part number MMTL-FEX-MP56, a 5.6 liter (1.5 gallon) sealed canister with a vacuum pump and a long flexible 7mm draw straw. Runs in manual hand pump mode or pneumatic mode off shop air (85 psi recommended, 120 psi maximum). Extracts low-viscosity fluids only, including engine oil, ATF, coolant, power steering fluid, and brake fluid; it is not for gear oil, most manual transmission fluid, or any thick or cold fluid. Warm the engine to operating temperature before extracting oil. Includes a bleeder screw adapter for one-person brake and hydraulic clutch bleeding, an automatic float shutoff to prevent overfill, and a removable lid for clean disposal. The 5.6L capacity covers a full single-engine Honda or Acura oil change with margin; for back-to-back changes or large coolant flushes, see the 9.5L MMTL-FEX-MP95. Backed by Mishimoto's Lifetime Warranty. One extractor per order.
Universal

Item	Use
5.6L fluid extractor canister	The pump and reservoir
Adapter hose	Connects pump output to draw straw or bleeder adapter
2mm draw straw (4 ft)	Smallest tubes, narrowest dipstick passages, brake fluid lines
4mm draw straw (4 ft)	Mid-sized tubes, smaller power steering reservoirs
6mm draw straw (4 ft)	Standard car dipstick tubes
7mm draw straw (4 ft)	Larger dipstick tubes, faster engine oil extraction
Bleeder screw adapter	Threads onto brake or clutch bleeder screws for hands-free bleeding
Air fitting	Connects canister to standard shop air quick-connect
